What Makes a 30 BBL Brite Tank Special?
The 30 BBL Brite Tank is made from certified food-grade stainless steel 304 or 316. It is designed to endure the challenges that a commercial brewhouse will face. Like all our tanks, this 30 BBL Brite Tank is put through a 48 hour stress test to ensure flawless performance when it arrives. You will get a total capacity of 37.5 BBL with an extra 25% unmarked headspace (including unmarked headspace). This allows you to comfortably deal with pressure shifts.
Key Features and Benefits
Unmatched Build Quality
The material of construction is Premium SUS304/SUS316 stainless steel. The structure has the 2B Internal Finish with Pickling Passivation for Sanitary purposes.
Moral Polished For Durability
The exterior of the structure has mirror-polished or brushed, which increases the aesthetic appeal and withstands the test of time.
Glycol Jacketed Cooling
Thermal Controls: PT100 temperature probe with optional digital display.
Pressure Resistance
Inner jacket is pressure tested to 0.4 MPa. The glycol jacket is pressure proofed to 0.5 MPa.
Multi-functional Design
Safe Mobility
Heavy-duty legs with leveling bolts, lifting ears, and top safety valve.
Carbonation-ready
360 Degree CIP
Effortlessly can be accessed through shadowless manway.
Real Applications of the 30 BBL Brite Tank
Both lagering and brightening along with brewpub direct-to-tap service or packaging for distribution, integrating the 30 BBL Brite Tank becomes a crucial component in your brewing flow.
Additional use cases include:
- Beer carbonation and clarifying it.
- Keg or can storing.
- Direct beer serving on tap lines during festivals or brew pubs.
Brewers have effective control over the yeast sedimentation and achieve consistently brilliant beer clarity owing to the large cooling surface area coupled with easy drainage.
Optional Enhancements
- Adjustable rotating racking arm
- Flexible liquid level display
- Digital display thermometer
- Siemens PLC or ABB PID control system
30 BBL Brite Tank specifications at a glance
| Feature | Specification |
|---|---|
| Effectice Volume | 30 BBL (3,510 liters) |
| Total Volume | 37.5 BBL (4,387 liters) |
| Dimensitons | Ø1800mm × H3050mm |
| Cooling Area | 5.3 m² |
| Material | SUS304 or SUS316 |
| Working pressure | 0.2 MPa (inner) / 0.3 MPa (cooling) |
| Finish options | Mirror, brushed and or pickled |
| Certifications | CE, ISO, ASME (on request) |
Ready to Invest in Brewing Excellence?
The 30 BBL Brite Tank is more than just a piece of equipment, it’s the cornerstone for any brewery focused on product quality and operational efficiency. Whether you are looking to brew for taste, clarity, or shelf life, this brite tank will exceed all expectations.
🛒 Contact us now for a quote and enhance your next brewing process.
Frequently Asked Questions (FAQ)
Q1: What is the actual volume of a 30 BBL Brite Tank?
A: The working volume is 30 BBL, while Total Volume is 37.5 BBL, offering a 25% headspace for carbonation and foam expansion.
Q2: Can this tank do fermentation and serving at the same time?
A: It can function as a serving tank or a secondary fermenter, but for bright beer, with the right fittings and pressure rating, it is best utilized as a serving tank.
Q3: What is the method of cooling the tank?
A: For smooth and uniform cooling, the unit has three glycol jacket zones (top, cone, and side) of the tank.
Q4: Is it provided with a carbonation stone?
A: Absolutely, each carbonating unit is provided with an integrated carbonation stone and sampling valve in addition to the 30 BBL brite tank.
Q5: Do you provide help with installation?
A: Yes, on demand, we provide remote technical support and complete turnkey brewery setup services.
